Akor Stainless is a well-respected manufacturer and supplier of stainless steel based in Abuja, Nigeria. They’re recognized for their precision-engineered stainless steel fittings that adhere to international quality standards. One of their standout products, the Stainless Steel Tee, is crafted to ensure reliable flow distribution and maintain connection integrity in piping systems. Using cutting-edge fabrication and finishing techniques, these fittings boast exceptional strength, corrosion resistance, and precise dimensions. Akor Stainless provides a range of Stainless Steel Tees in various sizes, grades, and configurations, catering to industries like chemical processing, oil and gas, water treatment, food production, and construction throughout Nigeria and West Africa.
Stainless Steel Tees from Akor Stainless are primarily made up of iron, chromium (16–20%), and nickel (8–12%), with trace amounts of molybdenum, manganese, and carbon to boost strength and corrosion resistance. Depending on the grade—typically 304, 316, or 316L—these tees deliver impressive resistance to oxidation, acids, and chloride attack. Mechanically, they showcase tensile strengths between 515–620 MPa, high toughness, and excellent weldability. Their consistent wall thickness and smooth internal surfaces promote efficient fluid flow, making them ideal for both high-pressure and hygienic applications across various industrial settings.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We ensure that every Stainless Steel Tee Fitting undergoes rigorous testing before leaving our premises, maintaining the highest quality standards at all times. Hardness Testing, Chemical Analysis (Spectro Analysis), Positive Material Identification (PMI Testing), Flattening Test, Micro and Macro Testing, Pitting Resistance Test, Flaring Test and Intergranular Corrosion (IGC) Testing are just some of the tests performed on Stainless Steel Tee Fittings before shipping.
Yes, stainless steel tees are fully recyclable. They can be melted down and reused without losing their properties, making them an environmentally friendly and sustainable material choice.
Common grades of stainless steel used in tee fittings manufacturing include 304, 304L, 316, 316L, and 321. These grades offer excellent corrosion resistance, durability, and suitability for various applications.
Yes, stainless steel tee fittings are ideal for hygienic and sanitary applications due to their corrosion resistance, smooth surfaces, and ease of cleaning, meeting strict industry standards.
Key considerations for selecting stainless steel tee fittings include material grade, corrosion resistance, pressure and temperature requirements, compatibility with media, application standards, and cost-effectiveness for long-term use.
Stainless Steel Tees from Akor Stainless play a crucial role in piping systems that need to branch or merge fluid flow. They’re extensively utilized in the oil and gas, petrochemical, and power generation sectors for process piping and pressure systems. In water treatment facilities, they efficiently distribute water flow. The food, beverage, and pharmaceutical industries rely on them for sanitary piping due to their smooth, corrosion-resistant surfaces. Additionally, they are commonly found in construction and HVAC installations.
