Akor Stainless is a top-notch manufacturer and supplier located in Abuja, Nigeria, focusing on high-quality Stainless Steel 316 Valves. With a strong dedication to innovation, precision engineering, and adhering to international quality standards, Akor Stainless provides durable and corrosion-resistant valve solutions that cater to a variety of industrial needs. Thanks to their modern facilities and a skilled team, every valve produced meets strict performance and reliability benchmarks. Industries in oil and gas, chemical processing, food, and pharmaceuticals trust Akor Stainless as a reliable partner for stainless steel fluid control systems, both in Nigeria and beyond.
Stainless Steel 316 Valves are primarily made up of iron, chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), along with small amounts of carbon, manganese, silicon, and phosphorus. The inclusion of molybdenum significantly boosts corrosion resistance, particularly in environments with chlorides and acids. These valves showcase impressive mechanical strength, with a tensile strength of around 515 MPa and a yield strength of about 205 MPa. They also retain good ductility, toughness, and hardness, even when exposed to high temperatures. Their exceptional mechanical and chemical stability makes them perfect for demanding industrial and marine applications.
| Material | Stainless Steel |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever |
| Operation Temperature | -10°C~150°C |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Stainless Steel 316 valves, available in sizes from 1/4″ to 12″, offer superior corrosion resistance and durability. Ideal for harsh environments, they ensure reliable performance in marine, chemical, and high-temperature applications.
Stainless Steel 316 ball valves, ranging from 1/4″ to 6″, provide smooth, reliable flow control with excellent corrosion resistance. Suitable for aggressive fluids and high-pressure environments, they ensure robust and long-lasting performance.
Stainless Steel 316 butterfly valves, available from 2″ to 12″, offer efficient flow regulation with high corrosion resistance. Their durable construction makes them ideal for use in chemical processing and marine applications.
Stainless Steel 316 globe valves, sized from 1″ to 12″, deliver precise flow control with exceptional corrosion resistance. Perfect for high-pressure and high-temperature applications in industrial and marine environments.
Stainless Steel 316 needle valves, available in sizes from 1/4″ to 2″, provide accurate flow control and high corrosion resistance. Ideal for handling aggressive fluids and high-pressure systems.
Stainless Steel 316 gate valves, sized from 1″ to 12″, offer reliable on/off flow control with excellent corrosion resistance. Suitable for marine, chemical, and industrial applications, they ensure durability and performance.
Akor Stainless ensures top-quality Stainless Steel 316 Valves through rigorous testing, including hardness, PMI, tensile, micro/macro structural, pitting resistance and IGC tests. We provide comprehensive documentation, including commercial invoices, packaging lists, labels and a Certificate of Origin legalized by the Chamber of Commerce or Embassy. A Third-Party Inspection Certificate guarantees customer satisfaction with pricing and delivery.
Stainless Steel 316 Valves find their place in industries that require high corrosion resistance and durability. They’re commonly used in oil and gas, chemical processing, marine, food and beverage, pharmaceuticals, and water treatment systems. These valves effectively manage the flow of liquids, gases, and steam under extreme conditions, making them ideal for pipelines, pressure vessels, and offshore settings. Their hygienic properties also make them a go-to choice in sanitary and process industries. With their long service life, reliability, and ability to withstand harsh environments, they prove to be a cost-effective option for critical flow control tasks.
