Akor Stainless, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in top-quality **Stainless Steel 304/304L Sanitary Tubing** that meets the highest hygiene and performance standards. These tubes are perfect for industries where purity, resistance to corrosion, and a smooth finish are non-negotiable. Akor Stainless takes pride in its precision manufacturing, exceptional polishing, and rigorous quality control for every tube they produce. Their 304/304L sanitary tubing is a trusted choice for clients in the food, beverage, dairy, pharmaceutical, and biotechnology sectors, thanks to its outstanding cleanliness, durability, and adherence to international sanitary standards.
**Stainless Steel 304/304L Sanitary Tubing** primarily consists of iron, with 18–20% chromium and 8–12% nickel. The 304L grade features a lower carbon content (≤0.03%), enhancing its weldability and corrosion resistance. These tubes boast a tensile strength of about 515 MPa and a yield strength of roughly 205 MPa, ensuring they are both durable and easy to shape. Their smooth inner surface reduces the risk of contamination, while their excellent resistance to oxidation and pitting makes them perfect for transporting hygienic fluids and for high-purity processing systems.
| ASTM | ASTM A270 / ASME SA 270 |
| Material | SS 304, SS 304L,SS 316,SS 316L |
| Outer Diameter | 1/2 Inch |
| Wall Thickness | 16 Gauge (0.065 Inch) |
| Length | 20 Feet |
| Finish | 20Ra Inner Diameter/ 32Ra Outer Diameter |
| Outer Diameter Tolerance | +/-0.005” / +/-0.13MM |
| Wall Thickness Tolerance | +/-10% |
| Length Tolerance | +1/8” / +3.18MM |
| Mill Test Certificate | EN10204 3.1 |
| Standard | 3A / ASTM A270 / A270M |
| Type | Seamless / Welded |
| Polish | Mechanical Polished / Electropolished |
| Certification | ASME BPE/ 3-A SSI |
| Grade | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Temperure | Yield Strength | Heat | Tensile Strength | Elongation |
| Min. º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
| TP304 | 1900 (1040) | 30(205) | Solution | 75(515) | 35 |
| TP304L | 1900 (1040) | 25(170) | Solution | 70(485) | 35 |
| TP316 | 1900(1040) | 30(205) | Solution | 75(515) | 35 |
| TP316L | 1900(1040) | 25(170) | Solution | 70(485) | 35 |
Contact us to get a quick quote for your requirement.
We ensure absolute clarity and premium quality assurance with our Stainless Steel 304/304L Sanitary Tubing. Each order is accompanied by a complete set of documentation, including a commercial invoice, packing list, fumigation certificate, heat treatment records, and NABL-certified laboratory test reports. Additionally, we provide Material Test Certificates (EN 10204/3.1b), Positive Material Identification (PMI) test reports, detailed radiographic examination records, and Third-Party Inspection Certificates. Our structured documentation process is specifically designed to ensure maximum transparency, strengthen client confidence, and deliver complete satisfaction.
304L has lower carbon content than 304, providing better weldability and reduced risk of carbide precipitation.
In food processing, breweries, dairy plants, pharmaceuticals, and biotechnology where hygiene and corrosion resistance are critical.
Tubing is typically manufactured as per ASTM A270, EN standards, and 3-A sanitary requirements.
Yes, suppliers provide Material Test Certificates (EN 10204/3.1), PMI reports, and sanitary compliance documents.
**Stainless Steel 304/304L Sanitary Tubing** is extensively utilized in industries where hygiene, purity, and corrosion resistance are paramount. It’s particularly suited for food processing, beverage production, dairy facilities, breweries, and pharmaceutical manufacturing. The tubing’s smooth interior surface helps prevent bacterial growth and allows for easy cleaning, making it ideal for sterile environments. Additionally, it finds applications in biotechnology, cosmetics, and chemical processing plants where contamination-free fluid transfer is critical. Its remarkable formability, weldability, and resistance to cleaning agents make it a top choice for sanitary and high-purity fluid handling systems.
