Home > Electrodes > AWS Class ER317L Mig & Tig Filler Welding Wire & Rod
Akor Stainless, a well-respected manufacturer and supplier located in Abuja, Nigeria, is dedicated to providing top-notch stainless steel welding consumables that adhere to international standards. One of their standout products is the AWS Class ER317L MIG and TIG Filler Welding Wire and Rod, crafted for exceptional corrosion resistance and mechanical strength. Renowned for its reliability, precision, and performance, Akor Stainless offers customized welding solutions for various industries, including chemical processing, marine, and food processing. With a strong emphasis on quality assurance and customer satisfaction, Akor Stainless has established itself as a trusted name in Nigeria’s stainless steel and welding supply sector.
The AWS Class ER317L MIG and TIG Filler Welding Wire and Rod is a low-carbon austenitic stainless steel alloy enriched with molybdenum to boost its resistance to pitting and crevice corrosion. Its typical makeup consists of about 19% chromium, 13% nickel, 3.5% molybdenum, and a maximum of 0.03% carbon. The mechanical properties include a tensile strength of roughly 550 MPa, yield strength of 350 MPa, and an elongation of 35%. These characteristics guarantee excellent weldability, toughness, and corrosion resistance, especially in chloride and acidic environments.
| Classification | AWS A5.9, ER317L |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER317L MIG & TIG Filler Metal Application & uses |
|
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.03 | 18.5-20.5 | 13.0-15.0 | 3.0-4.0 | 1.0-2.5 | 0.30-0.65 | 0.03 | 0.03 | 0.75 |
| Tensile Strength, kpsi: | 83* |
| Yield Strength, kpsi: | 60* |
| Elongation %: | 42* |
Contact us to get a quick quote for your requirement.
This MIG filler wire is available in sizes such as 0.030″, 0.035″, and 0.045″ diameter. It offers excellent corrosion resistance and is ideal for welding stainless steels with high molybdenum content. Its low carbon content helps minimize carbide precipitation.
Available in diameters like 1/16″, 3/32″, and 1/8″, this TIG filler wire provides superior corrosion resistance. It is suitable for welding similar stainless steel alloys and maintains a low carbon content to prevent carbide formation.
Typically offered in sizes of 1/16″, 3/32″, and 1/8″ diameter, this filler rod is known for its excellent resistance to corrosion and high strength. It’s designed for use in TIG welding applications requiring enhanced resistance to pitting and crevice corrosion.
After manufacturing, our quality control team conducts both destructive and non-destructive tests using advanced tools to ensure the performance and reliability of the AWS Class ER317L MIG and TIG Filler Welding Wire and Rod. Once tested we pack the products securely to maintain their quality during transit and ensure timely delivery to customers. All relevant documents are provided to clients at the time of delivery for full transparency and assurance.
The AWS Class ER317L MIG and TIG Filler Welding Wire and Rod is commonly used for welding stainless steels of similar composition and other high-alloy steels that demand superior corrosion resistance. It’s perfect for applications in chemical and petrochemical plants, pulp and paper mills, marine settings, and food processing equipment. Its low carbon content helps reduce carbide precipitation, preserving corrosion resistance in welded joints. Suitable for both MIG and TIG welding processes, ER317L ensures clean, smooth welds in piping systems, pressure vessels, heat exchangers, and structural components that face harsh, corrosive, or chloride-rich conditions.
